ENGINEERING BATCHING PLANT

Suitable for all kinds of engineering projects, special concrete mixing plants are customized and developed for engineering projects.

The whole machine is modularly designed, pre-installed and shipped in the factory, and can be installed on site in a modular manner, so as to achieve rapid installation and relocation.
It is suitable for different sites, different backstage layouts, different discharging directions, multiple powder silo groups, and various high-grade concrete production.

Specification

Model	HZSG60	HZSG90	HZSY120	HZSY180
Theoretical productivity(m³/h)	60	90	120	180
Installed capacity(kw)	100	190	210	250
Nominal capacity(l)	1000	1500	2000	3000
Unloading height(m)	≥3.8	≥3.8	≥3.8	≥3.8
Sandstone measuring range and accuracy(kg)	(600-2500)±2%	(600-2000)±2%	(600-2000)±2%	(900-3000)±2%
Cement measuring range and accuracy(kg)	(100-700)±1%	(200-1200)±1%	(200-1200)±1%	(300-1800)±1%
Mixing powder measuring range and accuracy(kg)	/	(200-800)±1%	(200-800)±1%	(200-1000)±1%
Water measuring range and accuracy(kg)	(80-250)±1%	(150-400)±1%	(150-400)±1%	(200-800)±1%
Additive measuring range and accuracy(kg)	(8-20)±1%	(15-50)±1%	(15-50)±1%	(15-80)±1%

Specification

Engineering batching plant are widely used in high-speed railways, highways, bridges, airports and other engineering fields. They are special mixing plants customized for engineering projects. Their design concept revolves around “high precision, high strength and high adaptability”. In terms of the metering system, multi-sensor dynamic compensation technology is adopted, with aggregate metering accuracy of ±1% and powder metering accuracy of ±0.5%. The three-level weighing calibration ensures that the ratio error is controlled within the strict industry standards. For special structures such as bridge piers and high-speed railway track plates, C60-C80 high-strength concrete can be produced. Some super-high-rise projects even support C100 and above grades. The construction performance under low water-cement ratio is achieved by optimizing the admixture compounding technology.
